1. Product name:
2. Material: metal
3. Weight: 135g
4. Color: black
5. Size: 9*6*2.5cm
6. Support resolution: 1080p@50/60Hz/1080i/720p/1576i/480p/480i
7. Support video color format: 24bits/deep color 30bit, 36bit
8. Audio output: L/R+ optical fiber
9. Maximum bandwidth: 340MHz
10. Maximum transfer rate: 10.2Gbps
11. Input/output TMDS signal: 0.5-1.5Volts p-p(TTL)
12. Input/output DDC signal: 5Volts p-p(TTL)
13. Input cable distance: 7m AWG26 standard cable HDMI
14. Output cable distance: 8m AWG26 standard cable HDMI
15. Maximum working current: 500mA
16. Power format: input AC (50/60Hz) 100V-240V; output: DC5V/1A
17. Operating temperature range: (-15 to +55°C)
18. Moderate working range: 5 to 90% RH (non-condensing)
19. Product features:
1) 1080P, separate audio and video synchronization, smart chip, plug and play, LED indicator
2) Strong heat dissipation, gold-plated ports, effectively enhance the signal
